Description

Specification:

Requirement: 4.5-18x50SF
Magnification low power: 4.5
Magnification high : 18
Clear aperture (mm): 50
Diopter range +/-: 2
Eye relief: 96
Standard Klick value for E/W (MIL): 1/10MIL
Total travel elevation (@ 100 yds): ≥ 45M0OA
Total travel windage (@ 100 yds): ≥ 45M0OA
Parallax Compensation: 15yds-∞
Fast focus eyepiece: yes
Sealing gas used: Nitrogen
Clear aperture min magnification (mm): 50
Clear aperture max magnification (mm): 50
Eff. exit pupil diameter @ min. magnification ± 3 %: 11.11
Eff. exit pupil diameter @ max. magnification ± 3 %: 2.78
Maximum resolution in Arc. Second (min. Magnification): 4
Maximum resolution in Arc. Second (max. Magnification): 4
Range of Function temperature (Unit can still be operated): -25°C/+55°C
Storage temperature: -40C to +85C
Range of Dioptric compensation +/- dpt: 2
Permissible backlash Dioptric Compensation: <0.25dpt objective field of view @ min magnification (ft @100yds): 28.3 objective field of view @ max magnification (ft@100yds): 7.1 Change of impact point after change of magnification (MOA): 1 Straightening of the Reticle: ± 2 ° Coating: FMC weight: 562g length: 320mm
