Description

Optical Performance

Magnification: 6.5-20x
Objective lens: 50mm diameter
Main tube diameter: 1″
MeoBright ion-assisted multi-coatings eliminate glare and reflections while delivering excellent light transmission

BDC Reticle

Bullet Drop Compensation reticle enables shooters to compensate for the amount a bullet drops over a particular distance
Positioned on the second (rear) focal plane

Use and Handling

Capped MeoTrak TRZ windage and elevation adjustments are numerically indexed
1/4 MOA per click impact point correction offers repeatability and dependability over a lifetime of use
MeoQuick fast-focus eyepiece rapidly brings your target into focus and provides diopter travel to accommodate a wider range of visual acuity variations

Side parallax adjustments

Eye releief: 3.5″
Exit pupil: 7.7 – 2.5mm

Construction Details

One-piece housing made of “ELOX” hard anodized aluminum alloy
Nitrogen-filled for fog-proof performance
MeoShield ion-assisted coating protects external lens surfaces and delivers enhanced resistance to scratching or abrasion in extreme conditions
Erector system designed to withstand heavy caliber recoil and eliminate backlash
Weight: 21.8 oz
