Description

FFP models also feature a zero stop elevation turret that allows the shooter to have a definite return-to-zero point no matter what distance they have dialed in for. Standard click values for non-MIL reticles are 0.25 MOA, while MIL based reticles feature 0.1 Milradian per click adjustments. Available in several reticle configurations including optional illumination and DichroTech, the 3-18×50 and 3-18×56 are designed with hunters and shooters in mind.

Magnification 3 – 18 x

Objective lens 56 mm

Objective Filter Thread M61x0.75

Main Tube Size 30 mm

Exit Pupil Diameter 9.5 – 3.1 mm

Eye relief (mm / in) 100 // 3.94

Field of view (m/100m // ft/100yds) 11.1-1.9 // 33.3-5.7

Field of View at 6.34 – 1.1 °

Focal Plane Position 2

Dioptric compensation -2 / 2 D

Daylight Transmission 91 %

Twilight Transmission 88 %

Twilight Factor 13 – 31.7

Impact per click (cm/100m // in/100yds) 0.7 // 0.26

Windage and elevation adjustment range (cm/100m // in/100yds) 262 // 94.3

Paralax Correction 10 yd – infinity y/n

Length (mm / in) 368 // 14.5

Weight (g / oz) 865 // 30.5

Windage and Elevation Adjustment Range (MOA) 90

AOL 14.5in
