Description

The JIANGSU-3L (often marketed under the IORMAN or Tuxing labels) is a high-performance composite vessel engineered for maximum portability and safety. The cylinder utilizes a seamless 6061 aluminum liner reinforced with a full-wrapped T700 carbon fiber and glass fiber filament winding, resulting in a 70% weight reduction compared to traditional steel tanks.

This specific kit comes with a high-pressure “Fill Station” valve that includes a luminous pressure gauge, a 50cm stainless steel braided micro-bore hose, and an 8mm female quick-disconnect. It is safety-certified (CE/EN12245) with a hydrostatic test pressure of 500 Bar, making it a reliable choice for fire-fighting, diving, and PCP rifle charging.

Specifications:

Water Capacity: 3.0 Liters

Working Pressure: 300 Bar (4500 PSI)

Test Pressure: 500 Bar (7500 PSI)

Materials: Carbon Fiber, Glass Fiber, and 6061 Aluminum Liner

Dimensions: Approx. 458mm (Height) x 114mm (Diameter)

Empty Weight: Approx. 2.1 kg – 2.5 kg (Cylinder only)

Thread Interface: M18 x 1.5

Service Life: 15 Years
