Description

Thermal Module:

Image Sensor :Uncooled Focal Plane Arrays

Max. Resolution :640×512

Frame Rate :50Hz

Pixel Interval :12μm

NETD :Less than 20mK (25 °C, F#=1.0)

Lens (Focal Length) :35mm, F0.9 AND 60mm, F1.1

Detection Range :1800m / 3000m

Focus Mode :Optical Zoom, Focus Ring

Field of View(H × V), Degrees / m @100m :12.5° ×10.0°/21.9m × 17.6m; 7.3° ×5.9°/12.8m × 10.2m

Min. Focusing Distance :35mm: 7m / 60mm: 9m
