Description

Specifications:

Model XP50 PRO
SKU 77461
Microbolometer
Type uncooled
Resolution, pixels 640×480
Pixel Pitch, µm 17
NETD, mK < 25
Frame rate, Hz 50
Optical Characteristics
Magnification, x 2.5
Continuous digital zoom, x 2.5-20
Digital zoom 2x/4x/8x
Objective lens 1:1.2
Close-up range, m / y 3 / 3.28
Exit pupil diameter, mm 5
Field of view (H), degrees / m@100m 12.4 / 21.8
Diopter adjustment, D ±5
Interpupillary distance adjustment, mm 56-71
Range of detection (deer type object), m (y) 1800 / 1970
Display
Type AMOLED
Resolution, pixels 640×480
Operational Characteristics
Power supply, V 3.7
Battery type / Capacity / Output voltage Li-Ion Battery Pack IPS7 / 6400 mAh / DC 3.7V (3.0-4.2)
External power supply 5V
Operating time on Battery Pack (at t=22°C), h* 9
Degree of protection, IP code (IEC60529) IPХ7
Operating temperature range, °С /° F -25 … +50 / -13 … 122
Dimensions, mm / inch 164 х 130 х 64 / 6.46 х 5.12 х 2.52
Weight (without battery), kg / oz 0.6 / 21.2
Video Recorder
Video / photo resolution, pixel 640×480
Video / photo format .avi / .jpg
Built-in memory 16 Gb
Built-in memory capacity 650 minutes of video or more than 100 000 photos
Wi-Fi Channel**
Frequency 2.4 GHz
Standard 802.11 b/g
Characteristics of the Rangefinder
Safety class for laser equipment according to BS / EN 60825-1: 2014 1
Wavelength, nm 905
Max. measuring range***, m/y 1000 / 1094
Measurement accuracy, m +/-1
