Description

Technical Specification:

Objective

magnification : 15
Effective objective lens diameter : 56 mm
Exit pupil diameter : 3.7 mm
exit-pupil-distance-eye-relief-mm : 16 mm
Field of view m at 1000m / ft at 1,000yds : 234 ft/1000 yds
Field of view degrees : 4.5°
Field of view for eyeglass wearers (°) : 4.5°
Field of view apparent : 62°
Shortest focusing distance : 12.8 ft
Diopter adjustment : ± 5dpt
Diopter correction at ∞ : 8dpt
Light transmission : 93%
Pupil distance : 2.2-3.0 in
Twilight factor acc. to ISO 14132-1 : 29

Size & weight

Length in mm. 7.56 in
Width in mm. 5.5 in
Height in mm. 2.87 in
Weight 42.3 oz

Environment & Conditions

Functional temperature : -13 to +131 °F
Storage temperature : -22 to +158 °F
Submersion tightness : 13 ft / 4 m water depth (inert gas filling)
